Cablaggio personalizzato con connettore a 5 e 7 pin
Custom Wire Harness with 5-Pin & 7-Pin Connector
- UL1061 28AWG
Custom Wire Harness with 5-Pin & 7-Pin Connector:
| Parameter | Specification |
| Connector A | 5-Pin Header (1.25mm Pitch, Straight Mate) |
| Connector B | 7-Pin Header (2.0mm Pitch, Right Angle) |
| Wire Specification | UL1061 28AWG (0.9mm OD) |
| Wire Length | Customizable |
| Insulation Resistance | ≥20MΩ @200V DC |
| Conductor Resistance | ≤3Ω Max |
| Hi-Pot Test | AC 100V/10ms Pass |
| Testing Protocol | 100% Continuity/Open/Short Test |
| Heat Shrink Tube | White, ID 3.0mm ×25mm |
| Temperature Range | -40°C to +105°C |
| Compliance | RoHS Certified |
Custom Wire Harness with 5-Pin & 7-Pin Connector:
High-Quality Custom Wire Harness for Reliable Connectivity:
This 5-pin to 7-pin wire harness provides secure signal transmission across industrial and
electronic applications. Built with UL1061-certified 28AWG wires, it delivers durability and
electrical stability while resisting abrasion and thermal stress.
Key Advantages:
Precision Connectors: 1.25mm pitch (5-pin) and 2.0mm pitch (7-pin) headers ensure
space-saving, robust connections.
Flexible Customization: Available in standard lengths or tailored designs with color-coded
wiring per pinout.
Strict Quality Control: 100% tested for continuity, insulation resistance (≥20MΩ), and
high-voltage safety (AC100V).
Heat-Shrink Protection: Includes white 3.0mm shrink tubing for strain relief and
environmental protection.
Ideal Applications:
Industrial control panels
Automotive sensors & displays
Medical diagnostics instruments
As Your Trusted Custom Wire Manufacturer, We Offer:
Prototype-to-Production Support
UL1061-Compliant Wires (80°C/300V rated)
Detailed Assembly Drawings for seamless integration
